 Classifies particles with a size of 5μm and smaller to be classified.
Completely eliminates particles of 1μm or larger in the sub-micron area.
Classifies aspherical particles and ramentum-formed particles.
Classifies foods and pharmaceuticals which need to be dismantled and cleaned.
| Model |
Classification Diameter [μm] |
Processing Capacity [kg/h] |
Suction Capacity [m3/min] |
Used Air Pressure Volume: [m3/min] |
Dimensions
(D X H) [mm] |
Weight [kg] |
| AC-20 |
0.3～20 |
1～20 |
1.5～3.0 |
～0.5 |
φ300×H400 |
50 |
| AC-30 |
0.5～25 |
2～40 |
3.0～6.0 |
～1.0 |
φ400×H600 |
100 |
| AC-40 |
1.0～30 |
4～80 |
8～12 |
～1.5 |
φ500×H800 |
200 |
| AC-80 |
1.5～30 |
16～320 |
32～48 |
～8 |
φ1000×H1200 |
500 |
| AC-Multi※ |
0.5～20 |
～120 |
- |
- |
- |
- |
* A Multi model at a new increased scale with improved performance in fine powder areas without any loss in accuracy is also available.
|
